1500 - 3000rpm Permanent Magnet Earth Magnet Motor B3/B35 Installation Mode

  • 1500 - 3000rpm Permanent Magnet Earth Magnet Motor B3/B35 Installation Mode
  • 1500 - 3000rpm Permanent Magnet Earth Magnet Motor B3/B35 Installation Mode
  • 1500 - 3000rpm Permanent Magnet Earth Magnet Motor B3/B35 Installation Mode
Place of Origin China
Brand Name Xicheng
Model Number TYB132-8-7.5-1500
Minimum Order Quantity 1PCS
Price $120-580/PCS
Delivery Time 7-15 work days
Payment Terms L/C,T/T
Supply Ability 500PCS 15-20work days

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Output 0.75-15Kw Working System S1
Efficiency 88.6%-95.3% Voltage 380V
Product Name Rare Earth Permanent Magnet Motor Speed 1500-3000rpm
Installation Mode B3/B35 Insulation Grade B
Highlight

1500rpm earth magnet motor

,

3000rpm earth magnet motor

,

fixed magnet motor IMB3
You can tick the products you need and communicate with us in the message board.
Type TYB80-8-0.75-3000 TYB80-8-1.1-3000 TYB90-8-1.5-3000 TYB90-8-2.2-3000 TYB112-8-3-2500 TYB112-8-4-2500 TYB132-8-5.5-2500 TYB132-8-5.5-1500 TYB132-8-7.5-1500 TYB132-8-7.5-3000 TYB132-8-11-3000 TYB132-8-15-3000
Voltage (V) 380 380 380 380 380 380 380 380 380 380 380 380
Erequency (Hz) 200 200 200 200 167 167 167 100 100 200 200 200
Output (Kw) 0.75 1.1 1.5 2.2 3 4 5.5 5.5 7.5 7.5 11 15
Speed (rpm) 3000 3000 3000 3000 2500 2500 2500 1500 1500 3000 3000 3000
Efficiency (%) 88.6 89.8 90.9 91.8 92.6 93.3 93.9 92.1 92.6 94.5 95 95.3
Working system S1 S1 S1 S1 S1 S1 S1 S1 S1 S1 S1 S1
Insulation grade B B B B B B B B B B B B
Installation mode B3/B35 B3/B35 B3/B35 B3/B35 B3/B35 B3/B35 B3/B35 B3/B35 B3/B35 B3/B35 B3/B35 B3/B35
Leave a Message
Type TYB80-8-0.75-3000 TYB80-8-1.1-3000 TYB90-8-1.5-3000 TYB90-8-2.2-3000 TYB112-8-3-2500 TYB112-8-4-2500 TYB132-8-5.5-2500 TYB132-8-5.5-1500 TYB132-8-7.5-1500 TYB132-8-7.5-3000 TYB132-8-11-3000 TYB132-8-15-3000
Product Description

1500 - 3000rpm Permanent Magnet Earth Magnet Motor B3/B35 Installation Mode

Product Description:

Our Rare Earth Permanent Magnet Motor is a top-quality product with excellent performance. It is built with rare earth permanent magnets for maximum efficiency and power, making it an ideal choice for any application requiring a reliable and powerful motor. The working system of the motor is S1, with an insulation grade of B, and can reach speeds of 1500-3000rpm. Additionally, it has a voltage of 380V and has an installation mode of B3/B35. It is the perfect motor for any job, featuring superior power and reliability.

Features:



  1. High efficiency and energy saving, first-class energy efficiency
  2. High power factor, improve grid quality factor
  3. High power density, convenient for energy-saving retrofit and upgrade
  4. The frequency range is wide, and it can still maintain high-efficiency operation under changing load conditions
  5. Integrated design of driver and motor, simple wiring and better motor protection





Technical Parameters:

Parameter Value
Product Name Rare Earth Permanent Magnet Motor
Insulation Grade B
Installation Mode B3/B35
Frequency 100-200Hz
Speed 1500-3000rpm
Output 0.75-15Kw
Working System S1
Efficiency 88.6%-95.3%
Voltage 380V


Applications:

Xicheng's Rare Earth Permanent Magnet Motor, with model number TYB132-8-7.5-1500, is designed with high-grade rare earth magnets, providing superior power and efficiency. This motor is manufactured in China and can be purchased in quantities as low as one piece with a price of $120-580/PCS. Delivery time is 7-15 work days, and payment terms are L/C,T/T. With a supply ability of 500PCS 15-20work days, this motor has an efficiency of 88.6%-95.3%, an insulation grade of B, and a speed range of 1500-3000rpm. With its rare earth permanent magnet design, this motor is ideal for powering a variety of industrial and commercial applications.



Support and Services:

Rare Earth Permanent Magnet Motor Technical Support and Service

We are committed to providing customers with superior technical support and service for Rare Earth Permanent Magnet Motors. Our team of experts is available to provide timely answers to any questions or concerns you may have.

If you encounter any issues with your Rare Earth Permanent Magnet Motor, please contact us directly and one of our experienced technicians will be happy to assist you.

1500 - 3000rpm Permanent Magnet Earth Magnet Motor B3/B35 Installation Mode 01500 - 3000rpm Permanent Magnet Earth Magnet Motor B3/B35 Installation Mode 11500 - 3000rpm Permanent Magnet Earth Magnet Motor B3/B35 Installation Mode 2

FAQ:



Q&A about Xicheng TYB132-8-7.5-1500 Rare Earth Permanent Magnet Motor
  • Q: What is the Brand Name of the Rare Earth Permanent Magnet Motor?
  • A: The Brand Name of the Rare Earth Permanent Magnet Motor is Xicheng.
  • Q: What is the Model Number of the Rare Earth Permanent Magnet Motor?
  • A: The Model Number of the Rare Earth Permanent Magnet Motor is TYB132-8-7.5-1500.
  • Q: Where is this Rare Earth Permanent Magnet Motor manufactured?
  • A: This Rare Earth Permanent Magnet Motor is manufactured in China.
  • Q: What's the minimum order quantity for this Rare Earth Permanent Magnet Motor?
  • A: The minimum order quantity for this Rare Earth Permanent Magnet Motor is 1PCS.
  • Q: What's the price range of this Rare Earth Permanent Magnet Motor?
  • A: The price range of this Rare Earth Permanent Magnet Motor is $120-580/PCS.
