750W - 15000W Permanent Magnet Rare Earth Motor High Power With Superior Insulation

  • 750W - 15000W Permanent Magnet Rare Earth Motor High Power With Superior Insulation
  • 750W - 15000W Permanent Magnet Rare Earth Motor High Power With Superior Insulation
  • 750W - 15000W Permanent Magnet Rare Earth Motor High Power With Superior Insulation
Place of Origin China
Brand Name Xicheng
Model Number TYB90-8-1.5-3000
Minimum Order Quantity 1PCS
Price $120-580/PCS
Delivery Time 7-15 work days
Payment Terms L/C,T/T
Supply Ability 500PCS 15-20work days

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Working System S1 Frequency 100-200Hz
Speed 1500-3000rpm Output 0.75-15Kw
Efficiency 88.6%-95.3% Installation Mode B3/B35
Insulation Grade B Voltage 380V
Highlight

750W rare earth motor

,

15000W rare earth motor

,

380V high power magnet motormagnet motor
You can tick the products you need and communicate with us in the message board.
Type TYB80-8-0.75-3000 TYB80-8-1.1-3000 TYB90-8-1.5-3000 TYB90-8-2.2-3000 TYB112-8-3-2500 TYB112-8-4-2500 TYB132-8-5.5-2500 TYB132-8-5.5-1500 TYB132-8-7.5-1500 TYB132-8-7.5-3000 TYB132-8-11-3000 TYB132-8-15-3000
Voltage (V) 380 380 380 380 380 380 380 380 380 380 380 380
Erequency (Hz) 200 200 200 200 167 167 167 100 100 200 200 200
Output (Kw) 0.75 1.1 1.5 2.2 3 4 5.5 5.5 7.5 7.5 11 15
Speed (rpm) 3000 3000 3000 3000 2500 2500 2500 1500 1500 3000 3000 3000
Efficiency (%) 88.6 89.8 90.9 91.8 92.6 93.3 93.9 92.1 92.6 94.5 95 95.3
Working system S1 S1 S1 S1 S1 S1 S1 S1 S1 S1 S1 S1
Insulation grade B B B B B B B B B B B B
Installation mode B3/B35 B3/B35 B3/B35 B3/B35 B3/B35 B3/B35 B3/B35 B3/B35 B3/B35 B3/B35 B3/B35 B3/B35
Leave a Message
Type TYB80-8-0.75-3000 TYB80-8-1.1-3000 TYB90-8-1.5-3000 TYB90-8-2.2-3000 TYB112-8-3-2500 TYB112-8-4-2500 TYB132-8-5.5-2500 TYB132-8-5.5-1500 TYB132-8-7.5-1500 TYB132-8-7.5-3000 TYB132-8-11-3000 TYB132-8-15-3000
Product Description

Efficient Rare Earth Permanent Magnet Motor with Superior Insulation

Product Description:

The Rare Earth Permanent Magnet Motor is a powerful and reliable motor designed for multiple applications. It features a 0.75-15Kw output, 380V voltage, 100-200Hz frequency, 88.6%-95.3% efficiency and 1500-3000rpm speed. It is suitable for both industrial and commercial applications and offers superior performance in a wide variety of applications. The motor is designed to meet the highest standards of quality and safety, providing an efficient and reliable solution for your needs. With its powerful performance and reliable design, the Rare Earth Permanent Magnet Motor is the perfect choice for your next project.



Features:



  • High efficiency and energy saving, first-class energy efficiency
  • High power factor, improve grid quality factor
  • High power density, convenient for energy-saving retrofit and upgrade
  • The frequency range is wide, and it can still maintain high-efficiency operation under changing load conditions
  • Integrated design of driver and motor, simple wiring and better motor protection





Technical Parameters:

Parameter Value
Product Name Rare Earth Permanent Magnet Motor
Speed 1500-3000rpm
Installation Mode B3/B35
Efficiency 88.6%-95.3%
Working System S1
Voltage 380V
Insulation Grade B
Frequency 100-200Hz
Output 0.75-15Kw


Applications:

The Rare Earth Permanent Magnet Motor from Xicheng is a reliable motor with model number TYB90-8-1.5-3000, made in China. It is available for purchase at $120-580/PCS, and delivery time is 7-15 work days. The payment terms are either L/C or T/T, and the supply ability is 500PCS 15-20work days. The installation mode is B3/B35, the frequency is 100-200Hz, the efficiency is 88.6%-95.3%, and the speed is 1500-3000rpm.

The Rare Earth Permanent Magnet Motor is an ideal choice for electric vehicles, robots, drones, and other industrial applications. It is designed to provide high torque and low speed, and is capable of operating in a wide range of temperatures. The rare earth permanent magnet motor is also capable of delivering high power output with minimal noise and vibration. Its long service life and low maintenance make it a great choice for a variety of applications.

The Rare Earth Permanent Magnet Motor from Xicheng is a reliable and cost-effective solution for a variety of industrial applications. Its durable construction and reliable performance make it a great choice for electric vehicles, robots, drones, and other industrial applications. If you are looking for a reliable and cost-effective motor, the Rare Earth Permanent Magnet Motor from Xicheng is the perfect solution.



Support and Services:

Technical Support and Service for Rare Earth Permanent Magnet Motor

We provide technical support and service for our Rare Earth Permanent Magnet Motor products. Our technical support team are available to answer any questions you may have about installation, use, and maintenance.

We also provide technical advice on how to optimise the performance of the motor and can help troubleshoot any problems you may be experiencing. We offer a range of technical support packages to suit your needs.

Our technical support team is available 24/7, and can provide assistance via phone, email, or live chat.

We are committed to providing our customers with the highest level of technical support and service. If you have any questions about our Rare Earth Permanent Magnet Motor products, please don't hesitate to get in touch.

750W - 15000W Permanent Magnet Rare Earth Motor High Power With Superior Insulation 0750W - 15000W Permanent Magnet Rare Earth Motor High Power With Superior Insulation 1750W - 15000W Permanent Magnet Rare Earth Motor High Power With Superior Insulation 2

FAQ:

Q. What is the brand name of the Rare Earth Permanent Magnet Motor?
A. The brand name of the Rare Earth Permanent Magnet Motor is Xicheng.
Q. What is the model number of the Rare Earth Permanent Magnet Motor?
A. The model number of the Rare Earth Permanent Magnet Motor is TYB90-8-1.5-3000.
Q. What is the place of origin of the Rare Earth Permanent Magnet Motor?
A. The place of origin of the Rare Earth Permanent Magnet Motor is China.
Q. What is the minimum order quantity of the Rare Earth Permanent Magnet Motor?
A. The minimum order quantity of the Rare Earth Permanent Magnet Motor is 1PCS.
Q. What is the price for one Rare Earth Permanent Magnet Motor?
A. The price for one Rare Earth Permanent Magnet Motor is $120-580/PCS.
