Energy Saving Permanent Magnet Driven Motor 1500 - 3000rpm Electric Magnetic Motor

  • Energy Saving Permanent Magnet Driven Motor 1500 - 3000rpm Electric Magnetic Motor
  • Energy Saving Permanent Magnet Driven Motor 1500 - 3000rpm Electric Magnetic Motor
  • Energy Saving Permanent Magnet Driven Motor 1500 - 3000rpm Electric Magnetic Motor
Place of Origin China
Brand Name Xicheng
Model Number TYB112-8-4-2500
Minimum Order Quantity 1PCS
Price $120-580/PCS
Delivery Time 7-15 work days
Payment Terms L/C,T/T
Supply Ability 500PCS 15-20work days

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Frequency 100-200Hz Insulation Grade B
Voltage 380V Working System S1
Installation Mode B3/B35 Output 0.75-15Kw
Speed 1500-3000rpm Efficiency 88.6%-95.3%
Highlight

Energy Saving Magnet Driven Motor

,

Magnet Driven Motor 1500RPM

,

3000rpm electric magnetic motor
You can tick the products you need and communicate with us in the message board.
Type TYB80-8-0.75-3000 TYB80-8-1.1-3000 TYB90-8-1.5-3000 TYB90-8-2.2-3000 TYB112-8-3-2500 TYB112-8-4-2500 TYB132-8-5.5-2500 TYB132-8-5.5-1500 TYB132-8-7.5-1500 TYB132-8-7.5-3000 TYB132-8-11-3000 TYB132-8-15-3000
Voltage (V) 380 380 380 380 380 380 380 380 380 380 380 380
Erequency (Hz) 200 200 200 200 167 167 167 100 100 200 200 200
Output (Kw) 0.75 1.1 1.5 2.2 3 4 5.5 5.5 7.5 7.5 11 15
Speed (rpm) 3000 3000 3000 3000 2500 2500 2500 1500 1500 3000 3000 3000
Efficiency (%) 88.6 89.8 90.9 91.8 92.6 93.3 93.9 92.1 92.6 94.5 95 95.3
Working system S1 S1 S1 S1 S1 S1 S1 S1 S1 S1 S1 S1
Insulation grade B B B B B B B B B B B B
Installation mode B3/B35 B3/B35 B3/B35 B3/B35 B3/B35 B3/B35 B3/B35 B3/B35 B3/B35 B3/B35 B3/B35 B3/B35
Leave a Message
Type TYB80-8-0.75-3000 TYB80-8-1.1-3000 TYB90-8-1.5-3000 TYB90-8-2.2-3000 TYB112-8-3-2500 TYB112-8-4-2500 TYB132-8-5.5-2500 TYB132-8-5.5-1500 TYB132-8-7.5-1500 TYB132-8-7.5-3000 TYB132-8-11-3000 TYB132-8-15-3000
Product Description

Energy Saving Permanent Magnet Magnet Driven Motor 1500 - 3000rpm Electric Magnetic Motor

Product Description:

The Magnet Driven Motor is the perfect choice for those seeking a permanent magnet drive integrated motor. With a voltage of 380V, a frequency of 100-200Hz, an efficiency of 88.6%-95.3%, and a speed of 1500-3000rpm, our Magnet Driven Motor offers the highest level of performance available. This motor is designed to meet the most demanding requirements of modern industry, and its high efficiency and reliability make it the ideal choice for applications that require a high-performance motor. With its reliable performance and excellent energy efficiency, our Magnet Driven Motor is an ideal choice for those looking for a reliable and efficient motor.



Features:



  1. High efficiency and energy saving, first-class energy efficiency
  2. High power factor, improve grid quality factor
  3. High power density, convenient for energy-saving retrofit and upgrade
  4. The frequency range is wide, and it can still maintain high-efficiency operation under changing load conditions
  5. Integrated design of driver and motor, simple wiring and better motor protection





Technical Parameters:

Parameter Value
Product Name Magnet Driven Motor
Installation Mode B3/B35
Working System S1
Voltage 380V
Insulation Grade B
Frequency 100-200Hz
Efficiency 88.6%-95.3%
Speed 1500-3000rpm
Output 0.75-15Kw


Applications:

Xicheng Magnet Driven Motor has a high efficiency of 88.6%-95.3%, and its output power is 0.75-15Kw. This Energy-saving Permanent Magnet Motor is equipped with 380V voltage, and the speed can reach 1500-3000rpm. This Permanent Magnet Synchronous Variable Frequency Motor is manufactured by Xicheng and its model number is TYB112-8-4-2500. You can order from 1PCS with a price of $120-580/PCS, and delivery time is 7-15 work days. We can provide 500PCS within 15-20 work days. Payment terms are L/C, T/T.



Support and Services:

Magnet Driven Motor Technical Support and Service

Our company provides technical support and service to help you get the most out of your Magnet Driven Motor. Our team of experienced engineers is available to assist you with any questions or issues you may have. Our team is committed to providing the highest quality of service and support to ensure your satisfaction.

 Energy Saving Permanent Magnet Driven Motor 1500 - 3000rpm Electric Magnetic Motor 0Energy Saving Permanent Magnet Driven Motor 1500 - 3000rpm Electric Magnetic Motor 1Energy Saving Permanent Magnet Driven Motor 1500 - 3000rpm Electric Magnetic Motor 2

FAQ:

Q: What is the Brand Name of Magnet Driven Motor?
A: The Brand Name of Magnet Driven Motor is Xicheng.
Q: What is the Model Number of Magnet Driven Motor?
A: The Model Number of Magnet Driven Motor is TYB112-8-4-2500.
Q: Where is the Place of Origin of Magnet Driven Motor?
A: The Place of Origin of Magnet Driven Motor is China.
Q: What is the Minimum Order Quantity of Magnet Driven Motor?
A: The Minimum Order Quantity of Magnet Driven Motor is 1PCS.
Q: What is the Price of Magnet Driven Motor?
A: The Price of Magnet Driven Motor is $120-580/PCS.
