Energy Saving Magnetic Driven Motor Insulation Grade B Industrial

  • Energy Saving Magnetic Driven Motor Insulation Grade B Industrial
  • Energy Saving Magnetic Driven Motor Insulation Grade B Industrial
  • Energy Saving Magnetic Driven Motor Insulation Grade B Industrial
Place of Origin China
Brand Name Xicheng
Model Number TYB112-8-4-2500
Minimum Order Quantity 1PCS
Price $120-580/PCS
Delivery Time 7-15 work days
Payment Terms L/C,T/T
Supply Ability 500PCS 15-20work days

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Speed 1500-3000rpm Output 0.75-15Kw
Product Name Magnet Driven Motor Voltage 380V
Insulation Grade B Installation Mode B3/B35
Frequency 100-200Hz Working System S1
Highlight

Energy Saving magnetic driven motor

,

magnetic driven motor Industrial

,

200Hz permanent magnet dc machine
You can tick the products you need and communicate with us in the message board.
Type TYB80-8-0.75-3000 TYB80-8-1.1-3000 TYB90-8-1.5-3000 TYB90-8-2.2-3000 TYB112-8-3-2500 TYB112-8-4-2500 TYB132-8-5.5-2500 TYB132-8-5.5-1500 TYB132-8-7.5-1500 TYB132-8-7.5-3000 TYB132-8-11-3000 TYB132-8-15-3000
Voltage (V) 380 380 380 380 380 380 380 380 380 380 380 380
Erequency (Hz) 200 200 200 200 167 167 167 100 100 200 200 200
Output (Kw) 0.75 1.1 1.5 2.2 3 4 5.5 5.5 7.5 7.5 11 15
Speed (rpm) 3000 3000 3000 3000 2500 2500 2500 1500 1500 3000 3000 3000
Efficiency (%) 88.6 89.8 90.9 91.8 92.6 93.3 93.9 92.1 92.6 94.5 95 95.3
Working system S1 S1 S1 S1 S1 S1 S1 S1 S1 S1 S1 S1
Insulation grade B B B B B B B B B B B B
Installation mode B3/B35 B3/B35 B3/B35 B3/B35 B3/B35 B3/B35 B3/B35 B3/B35 B3/B35 B3/B35 B3/B35 B3/B35
Leave a Message
Type TYB80-8-0.75-3000 TYB80-8-1.1-3000 TYB90-8-1.5-3000 TYB90-8-2.2-3000 TYB112-8-3-2500 TYB112-8-4-2500 TYB132-8-5.5-2500 TYB132-8-5.5-1500 TYB132-8-7.5-1500 TYB132-8-7.5-3000 TYB132-8-11-3000 TYB132-8-15-3000
Product Description

Energy-saving Magnet Driven Motor Insulation Grade B for Industrial Applications



Product Description:

Magnet Driven Motor is a type of permanent magnet synchronous variable frequency motor with a voltage of 380V, an output of 0.75-15Kw, a working system of S1, an installation mode of B3/B35, and an efficiency of 88.6%-95.3%. This type of motor is powered by permanent magnet and can provide high performance and reliability.With its excellent performance and energy efficiency, the Magnet-Driven Motor is the ideal choice for those who are looking for an efficient and reliable motor.



Parameter:

  • Product Name: Magnet Driven Motor
  • Output: 0.75-15Kw
  • Frequency: 100-200Hz
  • Speed: 1500-3000rpm
  • Voltage: 380V


Features of drive integrated permanent magnet motor:

  1.  High efficiency and energy saving, first-class energy efficiency
  2. High power factor, improve grid quality factor
  3. High power density, convenient for energy-saving retrofit and upgrade
  4. The frequency range is wide, and it can still maintain high-efficiency operation under changing load conditions
  5. Integrated design of driver and motor, simple wiring and better motor protection

Applications:

The product is a permanent magnet motor specially designed for fans,the efficiency index reaches the first-class standard of GB30253-2013 "Energy Efficiency Limits and Energy Efficiency Grades of Permanent Magnet Synchronous Motors",reach the international advanced level of similar products. It has a minimum order quantity of 1PCS, a price range of $120-580/PCS, and a delivery time of 7-15 work days. It has a frequency range of 100-200Hz, an installation mode of B3/B35, a speed range of 1500-3000rpm, and an insulation grade of B. It also has a supply ability of 500PCS with a delivery time of 15-20 work days. The Magnet Driven Motor is manufactured by Xicheng and is known for its high efficiency and energy-saving performance. It is the perfect choice for those looking for a reliable and cost-effective magnetic-driven motor.



Support and Services:

Magnet Driven Motor Technical Support and Service

We provide Technical Support and Services for the Magnet Driven Motor. Our experienced team of engineers can provide technical advice and support for product design, installation, and maintenance.

 Energy Saving Magnetic Driven Motor Insulation Grade B Industrial 0Energy Saving Magnetic Driven Motor Insulation Grade B Industrial 1Energy Saving Magnetic Driven Motor Insulation Grade B Industrial 2

FAQ:

Q: What is the Brand Name of this Magnet Driven Motor?
A: The Brand Name is Xicheng.

Q: What is the Model Number of this Magnet Driven Motor?
A: The Model Number is TYB112-8-4-2500.

Q: Where is this Magnet Driven Motor from?
A: This Magnet Driven Motor is from China.

Q: What is the Minimum Order Quantity for this Magnet Driven Motor?
A: The Minimum Order Quantity is 1PCS.

Q: What is the Price of this Magnet Driven Motor?
A: The Price of this Magnet Driven Motor is between $120-$580/PCS.

Q: How long is the Delivery Time for this Magnet Driven Motor?
A: The Delivery Time is 7-15 work days.

Q: What are the Payment Terms for this Magnet Driven Motor?
A: The Payment Terms are L/C,T/T.

Q: How many of this Magnet Driven Motor can be Supplied?
A: 500PCS can be Supplied in 15-20 work days.
