Permanent Magnet Driven Motor With B3/B35 Installation 0.75 - 15Kw 1500rpm

  • Permanent Magnet Driven Motor With B3/B35 Installation 0.75 - 15Kw 1500rpm
  • Permanent Magnet Driven Motor With B3/B35 Installation 0.75 - 15Kw 1500rpm
  • Permanent Magnet Driven Motor With B3/B35 Installation 0.75 - 15Kw 1500rpm
Place of Origin China
Brand Name Xicheng
Model Number TYB80-8-1.1-3000
Minimum Order Quantity 1PCS
Price $120-580/PCS
Delivery Time 7-15 work days
Payment Terms L/C,T/T
Supply Ability 500PCS 15-20work days

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Working System S1 Installation Mode B3/B35
Insulation Grade B Speed 1500-3000rpm
Output 0.75-15Kw Voltage 380V
Product Name Magnet Driven Motor Efficiency 88.6%-95.3%
Highlight

Magnet Driven Motor 0.75KW

,

Magnet Driven Motor 15Kw

,

Permanent Magnet Motor 1500rpm
You can tick the products you need and communicate with us in the message board.
Type TYB80-8-0.75-3000 TYB80-8-1.1-3000 TYB90-8-1.5-3000 TYB90-8-2.2-3000 TYB112-8-3-2500 TYB112-8-4-2500 TYB132-8-5.5-2500 TYB132-8-5.5-1500 TYB132-8-7.5-1500 TYB132-8-7.5-3000 TYB132-8-11-3000 TYB132-8-15-3000
Voltage (V) 380 380 380 380 380 380 380 380 380 380 380 380
Erequency (Hz) 200 200 200 200 167 167 167 100 100 200 200 200
Output (Kw) 0.75 1.1 1.5 2.2 3 4 5.5 5.5 7.5 7.5 11 15
Speed (rpm) 3000 3000 3000 3000 2500 2500 2500 1500 1500 3000 3000 3000
Efficiency (%) 88.6 89.8 90.9 91.8 92.6 93.3 93.9 92.1 92.6 94.5 95 95.3
Working system S1 S1 S1 S1 S1 S1 S1 S1 S1 S1 S1 S1
Insulation grade B B B B B B B B B B B B
Installation mode B3/B35 B3/B35 B3/B35 B3/B35 B3/B35 B3/B35 B3/B35 B3/B35 B3/B35 B3/B35 B3/B35 B3/B35
Leave a Message
Type TYB80-8-0.75-3000 TYB80-8-1.1-3000 TYB90-8-1.5-3000 TYB90-8-2.2-3000 TYB112-8-3-2500 TYB112-8-4-2500 TYB132-8-5.5-2500 TYB132-8-5.5-1500 TYB132-8-7.5-1500 TYB132-8-7.5-3000 TYB132-8-11-3000 TYB132-8-15-3000
Product Description

Reliable Performance Permanent Magnet Motor with B3/B35 Installation 0.75-15Kw

Product Description:

The Magnet Driven Motor is an energy-saving permanent magnet motor with a power range of 0.75-15Kw and a frequency of 100-200Hz. It has an installation mode of B3/B35 and an insulation grade of B. It is well-known for its outstanding efficiency, low noise and vibration, and high stability. It is a reliable and cost-effective choice for many industrial applications. This magnetic-driven motor is designed to provide reliable operation and superior performance. It is easy to install and maintain and is suitable for a wide range of applications including industrial, commercial, and residential. The Magnet Driven Motor is a perfect combination of advanced technology, superior quality, and reasonable price, making it the ideal choice for any industrial or commercial setting.



Features:



  • High efficiency and energy saving, first-class energy efficiency
  • High power factor, improve grid quality factor
  • High power density, convenient for energy-saving retrofit and upgrade
  • The frequency range is wide, and it can still maintain high-efficiency operation under changing load conditions
  • Integrated design of driver and motor, simple wiring and better motor protection





Technical Parameters:

Attribute Specification
Product Name Magnet Driven Motor
Efficiency 88.6%-95.3%
Insulation Grade B
Installation Mode B3/B35
Output 0.75-15Kw
Frequency 100-200Hz
Voltage 380V
Speed 1500-3000rpm
Working System S1


Applications:

Xicheng Magnet Driven Motor is an energy-saving permanent magnet motor, which is applicable for industrial automation. It is a permanent magnet synchronous variable frequency motor with high efficiency, low noise and minimum order quantity of 1PCS. The output is 0.75-15Kw, speed is 1500-3000rpm, insulation grade is B and voltage is 380V. The price range is from $120 to $580/PCS with delivery time of 7-15 work days. The payment terms are L/C, T/T and the supply ability is 500PCS 15-20work days. It is an ideal choice for industrial automation with its high performance and energy-saving features.



Support and Services:

Technical Support and Service for Magnet Driven Motor

We provide technical support and service to customers who have purchased our Magnet Driven Motor. Our technical support team is available to help you with any questions or issues you may have during the installation or operation of the motor. Our team is comprised of experienced engineers who can provide guidance and advice to ensure that your motor is functioning properly. We also offer a full range of repair services in the event that your motor needs to be repaired or replaced.

If you have any questions or issues, please contact us via phone, email, or online. We are here to help and provide the best customer service possible. Thank you for choosing our Magnet Driven Motor.

Permanent Magnet Driven Motor With B3/B35 Installation 0.75 - 15Kw 1500rpm 0Permanent Magnet Driven Motor With B3/B35 Installation 0.75 - 15Kw 1500rpm 1Permanent Magnet Driven Motor With B3/B35 Installation 0.75 - 15Kw 1500rpm 2

FAQ:

Magnet Driven Motor

Q1: What is the brand name of this Magnet Driven Motor?

A1: The brand name of this Magnet Driven Motor is Xicheng.

Q2: What is the model number of this Magnet Driven Motor?

A2: The model number of this Magnet Driven Motor is TYB80-8-1.1-3000.

Q3: Where is this Magnet Driven Motor made?

A3: This Magnet Driven Motor is made in China.

Q4: How many Magnet Driven Motors can I order at one time?

A4: You can order 1PCS at one time.

Q5: What is the price range for this Magnet Driven Motor?

A5: The price range for this Magnet Driven Motor is $120-580/PCS.

Tags:

IMB35 Magnet Driven Motor

Magnet Driven Motor 0.75KW

Permanent Magnet Driven Motor
