Powerful Permanent Magnet AC Motor IMB3 IMB35 Alternate Current Motor

  • Powerful Permanent Magnet AC Motor IMB3 IMB35 Alternate Current Motor
  • Powerful Permanent Magnet AC Motor IMB3 IMB35 Alternate Current Motor
  • Powerful Permanent Magnet AC Motor IMB3 IMB35 Alternate Current Motor
Place of Origin China
Brand Name Xicheng
Model Number TYB80-8-0.75-3000
Minimum Order Quantity 1PCS
Price $120-580/PCS
Delivery Time 7-15 work days
Payment Terms L/C,T/T
Supply Ability 500PCS 15-20work days

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Output 0.75-15Kw Insulation Grade B
Voltage 380V Frequency 100-200Hz
Working System S1 Installation Mode B3/B35
Product Name Permanent Magnet AC Motor Speed 1500-3000rpm
Highlight

Powerful Permanent Magnet AC Motor

,

Permanent Magnet AC Motor IMB3

,

IMB35 alternate current motor
You can tick the products you need and communicate with us in the message board.
Type TYB80-8-0.75-3000 TYB80-8-1.1-3000 TYB90-8-1.5-3000 TYB90-8-2.2-3000 TYB112-8-3-2500 TYB112-8-4-2500 TYB132-8-5.5-2500 TYB132-8-5.5-1500 TYB132-8-7.5-1500 TYB132-8-7.5-3000 TYB132-8-11-3000 TYB132-8-15-3000
Voltage (V) 380 380 380 380 380 380 380 380 380 380 380 380
Erequency (Hz) 200 200 200 200 167 167 167 100 100 200 200 200
Output (Kw) 0.75 1.1 1.5 2.2 3 4 5.5 5.5 7.5 7.5 11 15
Speed (rpm) 3000 3000 3000 3000 2500 2500 2500 1500 1500 3000 3000 3000
Efficiency (%) 88.6 89.8 90.9 91.8 92.6 93.3 93.9 92.1 92.6 94.5 95 95.3
Working system S1 S1 S1 S1 S1 S1 S1 S1 S1 S1 S1 S1
Insulation grade B B B B B B B B B B B B
Installation mode B3/B35 B3/B35 B3/B35 B3/B35 B3/B35 B3/B35 B3/B35 B3/B35 B3/B35 B3/B35 B3/B35 B3/B35
Leave a Message
Type TYB80-8-0.75-3000 TYB80-8-1.1-3000 TYB90-8-1.5-3000 TYB90-8-2.2-3000 TYB112-8-3-2500 TYB112-8-4-2500 TYB132-8-5.5-2500 TYB132-8-5.5-1500 TYB132-8-7.5-1500 TYB132-8-7.5-3000 TYB132-8-11-3000 TYB132-8-15-3000
Product Description

Powerful Permanent Magnet Alternating Motor for B3/B35 Installation

Product Description:

The Permanent Magnet Alternating Current Motor is a reliable and efficient motor system that is designed to provide superior performance in industrial applications. Its features include an operating voltage of 380V, a B-grade insulation system, and an S1 operating system. It also has an installation mode of B3/B35, making it suitable for different applications. With its permanent magnet design, the Permanent Magnet Alternating Motor is capable of delivering smooth and continuous power, making it an ideal choice for various industrial applications. The Permanent Magnet Motor is highly durable and reliable, ensuring long-term stability and performance.



Features:



  • High efficiency and energy saving, first-class energy efficiency
  • High power factor, improve grid quality factor
  • High power density, convenient for energy-saving retrofit and upgrade
  • The frequency range is wide, and it can still maintain high-efficiency operation under changing load conditions
  • Integrated design of driver and motor, simple wiring and better motor protection





Technical Parameters:

Parameters Values
Product Name Permanent Magnet AC Motor
Output 0.75-15Kw
Installation Mode B3/B35
Frequency 100-200Hz
Speed 1500-3000rpm
Insulation Grade B
Working System S1
Efficiency 88.6%-95.3%
Voltage 380V


Applications:

Xicheng’s Permanent Magnet Alternating Motor, model TYB80-8-0.75-3000, is a reliable and powerful motor manufactured in China. It is available to be purchased in a minimum order quantity of 1PCS and its price ranges from $120-580/PCS. The delivery time is estimated to be 7-15 work days, and customers can choose to pay by L/C or T/T. The supply ability is of 500PCS 15-20 work days. This permanent magnet motor has an installation mode of B3/B35, voltage of 380V, speed of 1500-3000rpm, and an efficiency of 88.6%-95.3%.



Support and Services:

Permanent Magnet AC Motor Technical Support and Service

  • 24/7 technical support
  • Telephone and online troubleshooting assistance
  • Flexible repair and return services
  • Spare parts supply
  • Regular product updates and upgrades
Powerful Permanent Magnet AC Motor IMB3 IMB35 Alternate Current Motor 0Powerful Permanent Magnet AC Motor IMB3 IMB35 Alternate Current Motor 1Powerful Permanent Magnet AC Motor IMB3 IMB35 Alternate Current Motor 2

FAQ:

Q: What is the brand name of the Permanent Magnet AC Motor?
A: The brand name of the Permanent Magnet AC Motor is Xicheng.
Q: What is the model number of the Permanent Magnet AC Motor?
A: The model number of the Permanent Magnet AC Motor is TYB80-8-0.75-3000.
Q: Where is the Permanent Magnet AC Motor produced?
A: The Permanent Magnet AC Motor is produced in China.
Q: What is the minimum order quantity of the Permanent Magnet AC Motor?
A: The minimum order quantity of the Permanent Magnet AC Motor is 1PCS.
Q: How much does one Permanent Magnet AC Motor cost?
A: One Permanent Magnet AC Motor costs between $120-580/PCS.
