11000m3/H Centrifugal Suction Fan Inner Dia Air Inlet 315 - 600mm

  • 11000m3/H Centrifugal Suction Fan Inner Dia Air Inlet 315 - 600mm
  • 11000m3/H Centrifugal Suction Fan Inner Dia Air Inlet 315 - 600mm
  • 11000m3/H Centrifugal Suction Fan Inner Dia Air Inlet 315 - 600mm
Place of Origin China
Brand Name Xicheng
Model Number 5#
Minimum Order Quantity 1PCS
Price $360-1320/PCS
Delivery Time 7-15 work days
Payment Terms L/C,T/T
Supply Ability 300PCS 20-30work days

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Outer Diameter Of Air Outlet 415~700mm Outer Diameter Of Air Inlet 415~700mm
Type Permanent Magnet Variable Frequency Centrifugal Fan Air Volume 2400~11000m³/H
Impeller Material PP/FRP Power 1.5~7.5Kw
Inner Diameter Of Air Outlet 315~600mm Speed 1450~3200r/min
Highlight

Centrifugal Suction Fan 315mm

,

Centrifugal Suction Fan 600mm

,

11000m3/H industrial exhaust fan
You can tick the products you need and communicate with us in the message board.
Type 3# 3# 3.6# 3.6# 4# 4# 4# 5# 5# 5# 6# 6#
Power （Kw） 1.5 1.5 2.2 2.2 3 4 3 7.5 5.5 4 5.5 7.5
Speed （r/min） 2900 3200 2900 3000 2750 2900 3200 2900 2415 1800 1450 2070
Impeller material PP PP PP PP PP FRP FRP FRP FRP PP PP FRP
Air volume (m³/H） 2400 2700 2600 2800 4500 5500 5000 10000 7000 9000 8000 11000
Wind presssure （Pa） 1000 1200 1200 1200 1200 1300 1300 1500 1500 1500 1000 1500
Air inlet 315-415 315-415 355-455 355-455 400-500 400-500 400-500 500-600 500-600 500-600 600-700 600-700
Air outlet 315-415 315-415 355-455 355-455 400-500 400-500 400-500 500-600 500-600 500-600 600-700 600-700
Leave a Message
Type 3# 3# 3.6# 3.6# 4# 4# 4# 5# 5# 5# 6# 6#
Product Description

Efficient Centrifugal Suction Fan with Inner Diameter of Air Inlet 315-600mm

Product Description:

Our Permanent Magnet Centrifugal Suction Fan is a highly efficient and reliable ventilation equipment. Made of PP and FRP material, it is suitable for industrial ventilation and dust removal. Its power ranges from 1.5Kw to 7.5Kw and its air volume can reach 2400-11000m³/h. The outer diameter of its air inlet is between 415-700mm, and its wind pressure reaches 1000-1500Pa. This Permanent Magnet Centrifugal Suction Machine is of superior quality and can provide a stable and safe working performance in any industrial environment. It is easy to install and requires minimal maintenance. As a reliable Permanent Magnet Centrifugal Suction Ventilator, it is widely applied in the ventilation and dust removal of industrial facilities, and it is also suitable for ventilation in commercial buildings.



Features:



The driver is integrated into the motor, in addition to meeting the drive needs of the permanent magnet motor, the chip in the driver still has a certain amount of spare computing power, and can be integrated into the driver according to the needs of customers.

For example, pressure sensor, temperature sensor, vibration sensor, remote control, display screen, etc., this is a set of closed-loop fan energy saving system, so that the fan system becomes more intelligent, and the energy saving effect is also improved again.





Technical Parameters:

Type Permanent Magnet Variable Frequency Centrifugal Fan
Power 1.5~7.5Kw
Outer diameter of air outlet 415~700mm
Inner diameter of air inlet 315~600mm
Impeller material PP/FRP
Speed 1450~3200r/min
Outer diameter of air inlet 415~700mm
Inner diameter of air outlet 315~600mm
Wind Pressure 1000~1500Pa
Air volume 2400~11000m³/H


Applications:

Xicheng's Permanent Magnet Centrifugal Suction Blower is the perfect solution for a wide range of applications. The 5# model has an outer diameter of air outlet from 415 to 700mm and an inner diameter of air inlet from 315 to 600mm. This fan is made from PP/FRP, with an air volume of 2400 to 11000m³/H and a speed range of 1450 to 3200r/min, making it one of the most powerful and efficient fans of its kind. It is available in quantities of one piece, with a price range of $360 to $1320 per piece, and delivery time of 7 to 15 work days. Payment options include L/C and T/T, and supply ability is 300 pieces with 20 to 30 work days.



Support and Services:

Centrifugal Suction Fan Technical Support and Service

We provide a full range of technical support and service for our Centrifugal Suction Fan. Our team of experienced professionals is available to assist with any questions you may have.

Our technicians can ensure that your fan is running at maximum efficiency and is performing up to its full capacity.

At Centrifugal Suction Fan, we are committed to providing the best customer service and technical support to ensure that you are satisfied with our products.

11000m3/H Centrifugal Suction Fan Inner Dia Air Inlet 315 - 600mm 011000m3/H Centrifugal Suction Fan Inner Dia Air Inlet 315 - 600mm 111000m3/H Centrifugal Suction Fan Inner Dia Air Inlet 315 - 600mm 2

FAQ:

Q&A
Q1: What is the Brand Name of this Centrifugal Suction Fan?
A1: The Brand Name is Xicheng.
Q2: What is the Model Number of this Centrifugal Suction Fan?
A2: The Model Number is 5#.
Q3: Where is the Place of Origin of this Centrifugal Suction Fan?
A3: The Place of Origin is China.
Q4: What is the Minimum Order Quantity of this Centrifugal Suction Fan?
A4: The Minimum Order Quantity is 1PCS.
Q5: What is the Price of this Centrifugal Suction Fan?
A5: The Price is $360-1320/PCS.
