Permanent Magnet FRP Centrifugal Fan Frequency Conversion Direct Drive 380V Anti Corrosion

  • Permanent Magnet FRP Centrifugal Fan Frequency Conversion Direct Drive 380V Anti Corrosion
  • Permanent Magnet FRP Centrifugal Fan Frequency Conversion Direct Drive 380V Anti Corrosion
  • Permanent Magnet FRP Centrifugal Fan Frequency Conversion Direct Drive 380V Anti Corrosion
Place of Origin China
Brand Name Xicheng
Model Number XC080-4
Minimum Order Quantity 1PCS
Price $860-2390/PCS
Delivery Time 7-15 work days
Supply Ability 300PCS 20-30work days

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Highlight

Permanent Magnet FRP Centrifugal Fan

,

FRP Centrifugal Fan 380V

,

exhaust fan for industrial use Anti Corrosion
You can tick the products you need and communicate with us in the message board.
Type XC030-1 XC030-2 XC040-1 XC040-2 XC040-3 XC040-4 XC050-1 XC050-2 XC050-3 XC050-4 XC060-1 XC060-2 XC060-3 XC060-4 XC070-2 XC070-3 XC070-4 XC080-1 XC080-2 XC080-3 XC080-4
Air inlet 450 450 600 600 600 600 750 750 750 750 900 900 900 900 1050 1050 1050 1200 1200 1200 1200
air outlet 410 410 550 550 550 550 680 680 680 680 820 820 820 820 940 940 940 1140 1140 1140 1140
power （Kw) 5.5 7.5 5.5 7.5 11 15 11 15 18.5 22 18.5 22 30 37 30 37 45 37 45 55 75
Air volume (m³/H） 7800 9000 12000 13800 15600 18000 20000 24000 27000 30000 36000 42000 48000 54000 57000 60000 66000 72000 78000 84000 90000
wind presssure（Pa） 1800 2000 1400 1600 1800 2000 1200 1400 1600 1800 1400 1600 1800 2000 1600 1800 2000 1600 1800 2000 2200
speed （r/min） 2150 2300 1620 1710 1825 2050 1297 1460 1550 1735 1175 1235 1470 1550 1050 1200 1350 1000 1100 1200 1280
Leave a Message
Type XC030-1 XC030-2 XC040-1 XC040-2 XC040-3 XC040-4 XC050-1 XC050-2 XC050-3 XC050-4 XC060-1 XC060-2 XC060-3 XC060-4 XC070-2 XC070-3 XC070-4 XC080-1 XC080-2 XC080-3 XC080-4
Product Description

Fiberglass fan Structural features:

1, motor: permanent magnet motor replaces asynchronous motor, efficiency increased by 5%-10%,

2, transmission: motor and fan impeller using direct connection mode, relative to the belt, belt pulley transmission mode efficiency increased by 3-5%,

3, impeller: with Xi 'an Jiaotong University joint development and design of binary and ternary impeller, the efficiency is 5-10% higher than that of ordinary impeller,

4. FRP bracket, corrosion resistant, acid and alkali resistant.

Permanent Magnet FRP Centrifugal Fan Frequency Conversion Direct Drive 380V Anti Corrosion 0Permanent Magnet FRP Centrifugal Fan Frequency Conversion Direct Drive 380V Anti Corrosion 1
